JVCU360 360 MEETING WEBCAM
System Requirements
• Available USB-C™ or USB™ Type-A port
• UVC 1.1 & UAC 1.0 support
• Windows® 10 / 8.1
• macOS® 10.14.11 or later with UVC support
• Chrome OS™ with UVC support
• Linux® (special configuration required)
Hardware
Host Connector USB-C® / USB™ 2.0 Type-A
Image Sensor 1/2.9” CMOS Sensor
Shutter Style N/A
Privacy Cover No
Protocol UVC 1.1 & UAC
Operating Voltage & Current DC5V/500 mA ±15 mA
Mounting Style N/A
LED Indicator
Red: Muted
Blue: Power on
Performance
Effective Pixels
Full Screen Mode: 1920(H) x 540(V)
360° All Around View Mode: 1920(H) x 720(V)
Host Mode: 1920(H) x 270(V), 1920(H) x 810(V)
Dual Host Mode: 1920(H) x 270(V), 960(H) x 810(V)
Single View Mode: 1920(H) x 1080(V)
Wide Angle View Mode: 120°(H), 88.6°
Megapixels 2 million pixels (2MP)
Output Format MJPEG
Frame Rate 30 FPS
Display Output Supported Resolutions
1920 x 1080
1280 x 720
640 x 480 / 360
Display FOV
Full Screen Mode: 2 – 180°(H), 53°(V)
360° All Around View Mode: 360°(H), 53°(V),
Host Mode: 360°(H) , 120°(H), 53°(V)
Dual Host Mode: 360°(H) , 60°(H), 53°(V)
Single View Mode: 90°(H), 58.5°(V)
Wide Angle View Mode: 120°(H), 88.6°
Maximum Display Refresh Rate 30 Hz
Microphone Built-in omnidirectional microphone
Physical Specifications
Color White, Black
Enclosure Type ABS
Lens Kit N/A
Cable Length 9.84 ft. (300 cm)
Product Height 7.6 in. (19.3 cm)
Product Width 3.68 in. (9.35 cm)
Product Depth 1.46 in. (3.7 cm)
Product Weight ≒12.35 oz (350g)
Storage Temperature –4°F to 140°F (-20°C to 60°C)
Storage Humidity < 90% non-condensing
Operating Temperature 41°F to 104°F (0°C to 40°C)
Operating Humidity < 90% non-condensing
Package Contents
• 1 – JVCU360 360° All Around Webcam
• 1 – Quick Installation Guide
