JVCU100 J5 1080 WEBCAM
System Requirements
• Available USB-C™ or USB™ Type-A port
• UVC 1.1/1.5 & UAC 1.0 support
• Windows® 10 / 8.1
• macOS® 10.14.11 or later with UVC support
• Chrome OS™ with UVC support
• Linux® (special configuration required)
Hardware
Host Connector USB™ 2.0 Type-A
Image Sensor 1/2.9” CMOS Sensor
Shutter Style Auto
Privacy Cover No
Protocol UVC 1.0/1.1/1.5 & UAC
Operating Voltage & Current DC5V/160 mA ±15 mA
Mounting Style Monitor clamp mount and tripod mount
LED Indicator
Red: Power on
Green: In use
Performance
Effective Pixels 1932(H) × 1088(V)
Megapixels 2 million pixels (2MP)
Output Format H.264, MJPEG, YUV2
Frame Rate 1080P/ 720P/ 640P at 30FPS
Display Output Supported Resolutions
H.264:
1920 x 1080 / 720
640 x 360
MJPEG:
1920 x 1080 / 720
640 x 360
YUV: 640 x 360
Display FOV 82°
Maximum Display Refresh Rate 30 Hz
Microphone Built-in high-fidelity microphone
Physical Specifications
Color Black
Enclosure Type ABS (Housing)/PC (Panel)
Lens Kit PC+30% GF (Housing)/Glass + COC (Lens)
Cable Length 4.92 ft. (150 cm)
Product Height 2.09 in. (5.3 cm)
Product Width 4.02 in. (10.2 cm)
Product Depth 2.11 in. (5.35 cm)
Product Weight ≒3.88oz (110g)
Storage Temperature –4°F to 140°F (-20°C to 60°C)
Storage Humidity < 90% non-condensing
Operating Temperature -4°F to 104°F (-20°C to 60°C)
Operating Humidity < 90% non-condensing
Package Contents
• 1 – USB™ HD Webcam with 360° rotation (Model: JVCU100)
• 1 – Quick Installation Guide
