Camera
-
Image Sensor: 1/2.8" CMOS
-
Max Resolution: 2304 × 1296 (3 MP)
-
Focal Length: 4.0 mm (Fixed)
-
Aperture: F2.0
-
Field of View:
-
Horizontal: 86.8°
-
Vertical: 47.1°
-
Diagonal: 102.2°
-
-
Illumination:
-
IR Distance: 30 m
-
Warm Light Distance: 30 m
-
-
Shutter Speed: Auto/Manual, 1s – 1/100,000s
-
Pan/Tilt Range:
-
Pan: 0°–345°
-
Tilt: 0°–+80°
-
Smart Features
-
IVS (Intelligent Video System): Tripwire, Intrusion Detection
-
Human Detection: Yes
-
SMD (Smart Motion Detection): Version 3.0
-
Light Warning:
-
Flash Duration: 5–30s
-
Flash Frequency: High, Medium, Low
-
-
Sound Warning:
-
1 built-in + 10 custom importable sounds
-
Adjustable volume (0%–100%)
-
Repeat: 1–10 times
-
Video & Audio
-
Compression:
-
Video: Smart H.265+, H.265, Smart H.264+, H.264, MJPEG
-
Audio: PCM, G.711a, G.711Mu, G.726
-
-
Resolutions Supported:
-
3M (2304 × 1296), 1080p, 960p, 720p, D1, CIF
-
-
Frame Rate:
-
Main: up to 30 fps
-
Sub: up to 30 fps
-
-
Bit Rate:
-
H.264: 88–8192 kbps
-
H.265: 35–8192 kbps
-
Network
-
Port: RJ-45 (10/100 Mbps)
-
Wi-Fi: IEEE 802.11b/g/n (2.4 GHz band)
-
Browser Support: IE 7+, Chrome, Firefox, Safari
-
Mobile App: iOS, Android
-
Software: Smart PSS, DMSS, ConfigTool, Smart Player
Storage
-
MicroSD Card: Up to 256 GB
-
FTP Upload: Supported
Dimensions & Weight
-
Dimensions:
-
Length: 14.05 cm
-
Diameter: 11.1 cm
-
-
Net Weight: 0.5 kg
-
Gross Weight (with packaging): 1 kg
Power & Environment
-
Power Supply: 12 VDC, 1A (included)
-
Operating Temp: –30 °C to +55 °C
-
Humidity: ≤95% (non-condensing)
-
Certifications: CE
