Print
Print Head / Consumables
-
Number of nozzles: Total 1,792 nozzles
-
Ink bottles (Type/Colours): GI-71 (Bundled), GI-71S (Pigment Ink/Black), (Dye-Based/Cyan, Magenta, Yellow)
-
Maintenance cartridge: MC-G07
-
Print heads: BH-70, CH-70
Maximum Print Resolution
-
4,800 (Horizontal) x 1,200 (Vertical) dpi
Print Speed (Approx.)
-
Document (ESAT/Simplex): 11 / 6 ipm (Mono/Colour)
-
Document (ESAT/Duplex): 8.3 / 5.2 ipm (Mono/Colour)
-
Document (FPOT Ready/Simplex): 9 / 14 sec (Mono/Colour)
-
Photo, 4 x 6" (PP-201/Borderless): 45 sec
Print Width
-
Up to 203.2 mm (8")
-
Borderless: Up to 216 mm (8.5")
Scan
Scanner Type
-
Flatbed (ADF/Platen)
Scanner Technology
-
Contact Image Sensor (CIS)
Optical Resolution
-
600 x 1,200 dpi
Scanning Bit Depth (Output)
-
Greyscale: 8 bit
-
Colour: RGB each 8 bit
Maximum Document Size
-
Flatbed: A4, LTR (216 x 297 mm)
-
ADF: A4, LTR, LGL
Copy
Copy Speed (Approx.)
-
Document (Colour) (sFCOT/Simplex)/(sESAT/Simplex): 23 sec / 3.2 ipm
-
Document (ADF) Mono/Colour (ESAT/Simplex): 9.6 / 1.8 ipm
Maximum Copies
-
99 pages
Maximum Document Size
-
A4, LTR, LGL
Reduction/Enlargement
-
25 – 400%
Copy Features
-
Borderless, Two-sided, Collate, 2-on-1, 4-on-1, Frame Erase, ID Copy, Oversized Copy
Paper Handling
Print Margin
-
Borderless printing (Top/Bottom/Left/Right): 0 mm
-
Bordered printing:
-
Envelopes (COM10, DL): Top 8 mm, Bottom 12.7 mm, Left/Right 3.4 mm
-
Envelope (C5, Monarch): Top 8 mm, Bottom 12.7 mm, Left/Right 5.6 mm
-
B-Oficio, M-Oficio: Top/Bottom 5 mm, Left/Right 6.4 mm
-
LTR, LGL, Foolscap, F4, Oficio2: Top/Bottom 5 mm, Left 6.4 mm, Right 6.3 mm
-
LGL (India): Top/Bottom 5 mm, Left/Right 5.9 mm
-
Square 5 x 5": All sides 6 mm
-
Square 3.5 x 3.5": All sides 5 mm
-
A6, A5, A4, B5, Executive: Top/Bottom 5 mm, Left/Right 3.4 mm
-
Custom Size (55 – 216 mm width, 89 – 1,200 mm length): Top/Bottom 5 mm, Left 3.4 mm, Right 3.4 – 9.4 mm
-
Others: Top 3 mm, Bottom 5 mm, Left/Right 3.4 mm
-
-
Bordered auto 2-sided printing: Top/Bottom 5 mm, Left/Right 3.4 mm (LTR: Left 6.4 mm, Right 6.3 mm)
Supported Media
-
Rear tray:
-
Plain Paper (64 – 105 g/m²)
-
High Resolution Paper (HR-101N)
-
Glossy Photo Paper (GP-508)
-
Photo Paper Plus Glossy II (PP-201, PP-208)
-
Photo Paper Pro Luster (LU-101)
-
Photo Paper Plus Semi-Gloss (SG-201)
-
Matte Photo Paper (MP-101)
-
Double-Sided Matte Photo Paper (MP-101D)
-
Envelope
-
Paper Size (Rear Tray)
-
A4, A5, A6, B5, LTR, LGL, Oficio2, B-Oficio, M-Oficio, Foolscap, F4, LGL (India), Executive, Envelopes (COM10, DL, C5, Monarch)
-
Photo Sizes: 4 x 6", 5 x 7", 7 x 10", 8 x 10", Square (89 x 89 mm, 127 x 127 mm), Card Size (91 x 55 mm)
-
Custom Size: Width 55 – 216 mm, Length 89 – 1,200 mm
Borderless Printing
-
A4, B5, LTR, 4 x 6", 5 x 7", 7 x 10", 8 x 10", Square (89 x 89 mm, 127 x 127 mm), Card Size (91 x 55 mm)
Auto 2-Sided Printing (Plain Paper 64 g/m²)
-
A4, LTR
Maximum Capacity
-
Rear Tray:
-
Plain Paper (A4, LTR, 64 g/m²): 100 sheets
-
High Resolution Paper (HR-101N): 80 sheets
-
Photo Paper Plus Glossy (PP-208, 4 x 6"): 20 sheets
-
Photo Paper Plus Semi-Gloss (SG-201, 4 x 6"): 20 sheets
-
Matte Photo Paper (MP-101, 4 x 6"): 20 sheets
-
-
Auto Document Feeder:
-
A4, LTR: 35 sheets
-
LGL: 5 sheets
-
Others: 1 sheet
-
Paper Weight
-
Plain Paper: 64 – 105 g/m²
-
Canon Paper (Photo Paper Plus Glossy II, PP-201): Approx. 265 g/m² (Max.)
Network
Protocol
-
SNMP, HTTP, TCP/IP (IPv4/IPv6)
Wireless LAN
-
Type: IEEE 802.11b/g/n
-
Frequency: 2.4 GHz
-
Supported Channels: 1 – 13 (Taiwan: 1 – 11 only)
Security
-
WPA-PSK (AES), WPA2-PSK (AES), WPA3-SAE (AES)
Direct Connection (Wireless LAN)
-
Available
Printing Solutions
Canon Printing Apps
-
Mobile: Canon PRINT, Easy-PhotoPrint Editor, Creative Park
-
Others: Easy-Layout Editor, PosterArtist Lite, PosterArtist (Web), Canon Inkjet Smart Connect
Mobile/Cloud Printing Solutions
-
AirPrint, Mopria Print Service, Canon Print Service (Android), Direct Wireless, Cloud Integration Service
System Requirements
-
Windows 11 / 10 / 8.1 / 7 SP1
-
macOS 11.7.6 ~ 14 or later
-
ChromeOS
General Specifications
Operation Panel
-
Display: 2.7" LCD (Touchscreen, Colour)
Interface
-
USB 2.0
Operating Environment
-
Temperature: 5 – 35°C
-
Humidity: 10 – 90% RH (no dew condensation)
Recommended Environment
-
Temperature: 15 – 30°C
-
Humidity: 10 – 80% RH (no dew condensation)
Storage Environment
-
Temperature: 0 – 40°C
-
Humidity: 5 – 95% RH (no dew condensation)
Quiet Mode
-
Available
Acoustic Noise (PC Print)
-
Plain Paper (A4, Mono): 49.0 dB(A)
Power Requirements
-
AC 100 – 240 V, 50/60 Hz
Power Consumption (Approx.)
-
OFF: 0.1 W
-
Standby (USB connection to PC): 0.9 W
-
Operation: 18 W
Duty Cycle
-
Up to 3,000 pages/month
Dimensions (W x D x H)
-
Factory Configuration: 416 x 363 x 212 mm
-
Output/ADF Trays Extended: 416 x 554 x 268 mm
Weight
-
7.5 kg
Page Yield (Plain Paper)
-
GI-71 PGBK: 6,000 pages (Economy Mode: 7,600)
-
GI-71 C, M, Y: 7,700 pages (Economy Mode: 8,100)
-
GI-71S PGBK: 3,100 pages (Economy Mode: 3,900)
-
GI-71S C, M, Y: 4,400 pages (Economy Mode: 4,600)
Page Yield (Photo Paper PP-201, 4 x 6")
-
GI-71 C, M, Y: 2,200 pages
-
GI-71S C, M, Y: 1,200 pages
-
GI-71 PGBK and GI-71S PGBK: Not applicable
