Print Head / Ink

Number of Nozzles

Total 1,792 nozzles

Ink Bottles (Type / Colours)

GI-71, GI-71S (Bundled)
(Pigment Ink / Black),
(Dye-Based Ink / Cyan, Magenta, Yellow)

Maintenance Cartridge

MC-G04

Maximum Printing Resolution

4,800 (horizontal)^*1 x 1,200 (vertical) dpi

Print Speed^*2 (Approx.)

Based on ISO/IEC 24734
Click here for Document Print and Copy Speed Measurement Conditions

Document (ESAT / Simplex)

11 / 6 ipm (mono/colour)

Document (FPOT Ready / Simplex)

9 / 14 sec (mono/colour)

Photo (4 x 6") (PP-201 / Borderless)

45 sec

Printable Width

Up to 203.2 m (8")
Borderless: Up to 216 mm (8.5")

Print Margin

Borderless Printing

Top/Bottom/Left/Right margin: 0 mm

Bordered Printing

Envelopes (COM10, DL):
Top margin: 8 mm, Bottom margin: 12.7 mm
Left/Right margin: 3.4 mm

Envelopes (C5, Monarch)
Top margin: 8 mm, Bottom margin: 12.7 mm
Left/Right margin: 5.6 mm

B-Oficio, M-Oficio:
Top margin: 3 mm, Bottom margin: 5 mm
Left/Right margin: 6.4 mm

LTR, LGL, Foolscap, F4, Oficio2
Top margin: 3 mm, Bottom margin: 5 mm
Left margin: 6.4 mm, Right margin: 6.3 mm

Legal (India)
Top margin: 3 mm, Bottom margin: 5 mm
Left/Right margin: 5.9 mm

Square 5 x 5" (127 x 127 mm):
Top/Bottom/Left/Right margin: 6 mm

Square 3.5 x 3.5" (89 x 89 mm):
Top/Bottom/Left/Right margin: 5 mm

Custom Size:
Width 55 – 216 mm, Length: 89 – 1,200 mm
Top margin: 3 mm, Bottom margin: 5 mm
Left margin: 3.4 mm, Right margin: 3.4 – 9.4 mm

Others:
Top margin: 3 mm, Bottom margin: 5 mm
Left/Right margin: 3.4 mm

Supported Media

Rear Tray

Plain Paper (64 – 105 g/m²)
High Resolution Paper (HR-101N)
Photo Paper Plus Glossy II (PP-201, PP-208)
Photo Paper Plus Semi-Gloss (SG-201)
Glossy Photo Paper (GP-508)
Photo Paper Pro Luster (LU-101)
Matte Photo Paper (MP-101)
Double Sided Matte Photo Paper (MP-101D)
Envelope
Photo Stickers (PS-208/PS-808)

Paper Size

Rear Tray

A4, A5, A6, B5, LTR, LGL, Executive, Oficio 2,
B-Oficio , M-Oficio, Legal (India), Foolscap, F4,
4 x 6", 5 x 7", 7 x 10", 8 x 10", Envelopes (DL, COM10, C5, Monarch), Square (89 x 89 mm, 127 x 127 mm), Card Size (91 x 55 mm)

[Custom Size] Width: 55 – 216 mm
Length: 89 – 1,200 mm

Paper Size (Borderless)^*3

A4, B5, LTR, 4 x 6", 5 x 7", 7 x 10", 8 x 10", Square (89 x 89 mm, 127 x 127 mm), Card Size (91 x 55 mm)

Paper Handling (Maximum Number)

Rear Tray

[Photo Paper, 4 x 6"] Photo Paper Plus Glossy II (PP-201): 20
Photo Paper Plus Semi-Gloss (SG-201): 20
Glossy Photo Paper (GP-508): 20
Matte Photo Paper (MP-101): 20
Photo Paper Plus Glossy II (PP-208): 10

Paper Weight

Rear Tray

Plain Paper: 64 – 105 g/m²
Canon Paper: Max. 265 g/m²
(Photo Paper Plus Glossy II, PP-201)

Ink End Sensor

Dot count type

Print Head Alignment

Manual

Scanner Type

Flatbed

Scanner Method

Optical Resolution^*5

600 x 1,200 dpi

Scanning Bit Depth (Input / Output)

Greyscale

16 bit / 8 bit

Colour

RGB each 16 bit / 8 bit

Line Scanning Speed^*6 (Approx.)

Greyscale

1.5 ms/line (300 dpi)

Colour

3.5 ms/line (300 dpi)

Maximum Document Size

Flatbed

A4, LTR (216 x 297 mm)

Compatible Media

Size

A4, A5, A6, B5, LTR, Executive (184.2 × 266.7 mm), 4 x 6", 5 x 7", Square (127 x 127 mm), Card Size (91 x 55 mm)

Type

Plain Paper (64 – 105 g/m²)
Photo Paper Plus Glossy II (PP-201, PP-208)
Photo Paper Pro Luster (LU-101)
Glossy Photo Paper (GP-508)
Photo Paper Plus Semi-Gloss (SG-201)
Matte Photo Paper (MP-101)

Image Quality

Density Adjustment

9 positions, Auto Intensity (AE copy)

Copy Speed^*7 (Approx.)

Based on ISO/IEC 24734
Click here for Document Print and Copy Speed Measurement Conditions

Document (Colour): (sFCOT/Simplex) / (sESAT/Simplex)

23 sec / 2.7 ipm

Multiple Copy

Mono / Colour

Max. 99 pages

Maximum Document Size

A4 / LTR

Windows 11 / 10 / 8.1 / 7 SP1
(operation can only be guaranteed on a PC with a pre-installed Windows 7 or later)

macOS 10.14.6 – 12 or later

Chrome OS

Interface

USB 2.0

Operating Environment^*9

Temperature

5 – 35°C

Humidity

10 – 90% RH (no dew condensation)

Recommended Environment^*10

Temperature

15 – 30°C

Humidity

10 – 80% RH (no dew condensation)

Storage Environment^*9

Temperature

0 – 40°C

Humidity

5 – 95% RH (no dew condensation)

Quiet Mode

Available

Acoustic Noise (PC Print) (Approx.)

Plain Paper (A4, Mono)^*11

47.5 dB(A)

Power

AC 100 – 240 V, 50/60 Hz

Power Consumption (Approx.)

OFF

0.1 W

Standby (scanning lamp is off)
USB connection to PC

0.6 W

Copying^*12
(USB connection to PC)

15 W

Duty Cycle

Up to 3,000 pages/month

Dimensions (WxDxH) (Approx.)

Factory Configuration

416 x 337 x 177 mm

Output / Trays Extended

416 x 557 x 268 mm

Weight (Approx.)

6 kg

Plain Paper (A4 pages)
(ISO/IEC 24712 test file)^*13

Standard:
GI-71 PGBK: 6,000
GI-71 C, M, Y: 7,700^*14

GI-71S PGBK: 3,100
GI-71S C, M, Y: 4,400^*14

Economy^*15:
GI-71 PGBK: 7,600
GI-71 C, M, Y: 8,100^*14

GI-71S PGBK: 3,900
GI-71S C, M, Y: 4,600

GI-71S PGBK: NA^*16
GI-71S C, M, Y: 1,200
