HP-SFF400-G9-INTELCOREI5-13500,8GBR5,512GBSSD,INTELHD,W11PRO,1YR

HP-SFF400-G9-INTELCOREI5-13500,8GBR5,512GBSSD,INTELHD,W11PRO,1YR

Operating system

INCLUDED IN CURRENT CONFIGURATION

Windows 10 Pro (available through downgrade rights from Windows 11 Pro)

ALTERNATE OPTIONS

Windows 11 Pro – HP recommends Windows 11 Pro for business
FreeDOS

Processor

INCLUDED IN CURRENT CONFIGURATION

Intel® Core™ i3-12100 Processor (3.3 GHz, up to 4.3 GHz w/Boost, 12 MB cache, 4 core, 60W) + Intel® UHD Graphics 730

ALTERNATE OPTIONS

Intel® Pentium® Gold G7400 Processor (3.7 GHz, 6 MB cache, 2 core, 46W) + Intel® UHD Graphics 710
Intel® Core™ i3-12300 Processor (3.5 GHz, up to 4.4 GHz w/Boost, 12 MB cache, 4 core, 60W) + Intel® UHD Graphics 730
Intel® Core™ i5-12500 Processor (3.0 GHz, up to 4.6 GHz w/Boost, 18 MB cache, 6 core, 65W) ECC + Intel® UHD Graphics 770
Intel® Core™ i5-12600 Processor (3.3 GHz, up to 4.8 GHz w/Boost, 18 MB cache, 6 core, 65W) + Intel® UHD Graphics 770
Intel® Core™ i7-12700 Processor (2.1 GHz, up to 4.9 GHz w/Boost, 25 MB cache, 12 core, 65W) + Intel® UHD Graphics 770
Intel® Core™ i3-13100 Processor (3.4 GHz, up to 4.5 GHz w/Boost, 12 MB cache, 4 core, 60W) + Intel® UHD Graphics 730
Intel® Core™ i5-13500 Processor (2.5 GHz, up to 4.8 GHz w/Boost, 24 MB cache, 14 core, 65W) + Intel® UHD Graphics 770
Intel® Core™ i5-13600 Processor (2.7 GHz, up to 5.0 GHz w/Boost, 24 MB cache, 14 core, 65W) + Intel® UHD Graphics 770
Intel® Core™ i7-13700 Processor (2.1 GHz, up to 5.2 GHz w/Boost, 30 MB cache, 16 core, 65W) + Intel® UHD Graphics 770

ENERGY STAR compliance

INCLUDED IN CURRENT CONFIGURATION

ENERGY STAR Qualified Configuration

TCO Certified compliance

INCLUDED IN CURRENT CONFIGURATION

Compliant with TCO Certified

Base features

INCLUDED IN CURRENT CONFIGURATION

HP Pro Small Form Factor 400 G9 – 240 W (12th Generation Processor) – 526G1AV

ALTERNATE OPTIONS

HP Pro Small Form Factor 400 G9 – 180 W (13th Generation Processor) – 7E8X8AV

Memory

INCLUDED IN CURRENT CONFIGURATION

8 GB (1 x 8 GB) DDR4-3200 UDIMM Memory

ALTERNATE OPTIONS

4 GB (1 x 4 GB) DDR4-3200 UDIMM Memory
8 GB (2 x 4 GB) DDR4-3200 UDIMM Memory
16 GB (1 x 16 GB) DDR4-3200 UDIMM Memory
16 GB (2 x 8 GB) DDR4-3200 UDIMM Memory
32 GB (1 x 32 GB) DDR4-3200 UDIMM Memory
32 GB (2 x 16 GB) DDR4-3200 UDIMM Memory
64 GB (2 x 32 GB) DDR4-3200 UDIMM Memory

Internal M.2 storage

INCLUDED IN CURRENT CONFIGURATION

256 GB PCIe 4×4 2280 NVMe TLC SSD

ALTERNATE OPTIONS

256 GB PCIe NVMe Value SSD
256GB PCIe 2280 NVMe OPAL 2 Self-Encrypted (SED) Value SSD
256 GB PCIe 4×4 2280 NVMe OPAL 2 Self-Encrypted (SED) TLC SSD
512 GB PCIe 4×4 2280 NVMe TLC SSD
512 GB PCIe 4×4 2280 NVMe OPAL 2 Self-Encrypted (SED) TLC SSD
1 TB PCIe 4×4 2280 NVMe TLC SSD
2 TB PCIe 4×4 2280 NVMe TLC SSD

Internal storage

ALTERNATE OPTIONS

500 GB 7200 RPM 3.5" HDD
1 TB 7200 RPM SATA 3.5" HDD
2 TB 7200 RPM SATA 3.5" HDD

Graphics card

ALTERNATE OPTIONS

AMD RADEON RX 6300 2 GB GDDR6 LP DP+HDMI PCIE X16 GRAPHICS
NVIDIA® T400 (4 GB GDDR6, 3 x Mini DisplayPort) Graphics
NVIDIA® T400 (4 GB GDDR6, 2 Mini DisplayPort-to-DisplayPort Adapter) Graphics
NVIDIA® T400 (4 GB GDDR6, 2 Mini DisplayPort-to-DVI Adapter) Graphics

Additional networking options

ALTERNATE OPTIONS

Intel® Wi-Fi 6E AX211 160MHz + Bluetooth® 5.2
Intel® Wi-Fi 6E AX211 160MHz + Bluetooth® 5.3 (vPro)
Intel Ethernet Network Adapter I225-T1 (Fox Pond)

Optical drive

INCLUDED IN CURRENT CONFIGURATION

No included Optical Disc Drive

ALTERNATE OPTIONS

DVD-ROM
DVD-Writer

Keyboard

INCLUDED IN CURRENT CONFIGURATION

HP USB 320K Keyboard

ALTERNATE OPTIONS

No Included Keyboard
HP USB Business Slim Wired SmartCard CCID Keyboard
Wireless Keyboard and Mouse Combo

Mouse

INCLUDED IN CURRENT CONFIGURATION

HP Black 125 Wired Mouse

ALTERNATE OPTIONS

No Mouse Included
HP Wired 128 Laser Mouse

Power supply

INCLUDED IN CURRENT CONFIGURATION

C13 1.83m Sticker Conventional Straight Desktop Power Cord

Security management

Trusted Platform Module TPM 2.0 Embedded Security Chip shipped with Windows 10 (Common Criteria EAL4+ Certified)(FIPS 140-2 Level 2 Certified); HP Secure Erase; HP Sure Click; Absolute Persistence module; HP Sure Admin; HP Tamper Lock; HP Sure Start Gen7; HP Sure Sense2[16,17,18,19,20,21,22,23]

Management software

HP Client Catalog (download); HP Driver Packs (download); HP Image Assistant (download); HP Client Management Script Library (download); HP Manageability Integration Kit Gen 4 (download)

Accessories (optional)

ALTERNATE OPTIONS

HP SFF Chassis Tower Stand

External I/O Ports

Front : 1 headphone/microphone combo; 1 SuperSpeed USB Type-C® 10Gbps signaling rate; 3 SuperSpeed USB Type-A 10Gbps signaling rate
Rear : 1 audio-out; 1 power connector; 1 RJ-45; 1 HDMI 1.4; 3 SuperSpeed USB Type-A 5Gbps signaling rate; 1 DisplayPort™ 1.4; 2 USB Type-A 480Mbps signaling rate

Management features

HP Client Catalog (download); HP Driver Packs (download); HP Image Assistant (download); HP Client Management Script Library (download); HP Manageability Integration Kit Gen 4 (download)[7]

Audio Features

Realtek ALC3252 codec, universal audio jack with CTIA and OMTP headset support

Expansion slots

1 M.2 2230; 1 M.2 2280; 1 PCIe 3 x1; 1 PCIe 4 x161 M.2 2230 slot for WLAN or storage and 1 M.2 2280 slot for storage.

Memory slots

2 DIMM

Compliance options

INCLUDED IN CURRENT CONFIGURATION

ENERGY STAR Qualified Configuration

Warranty

INCLUDED IN CURRENT CONFIGURATION

One-year (1/1/1) limited warranty

Software included

HP Notifications; HP PC Hardware Diagnostics UEFI; HP Support Assistant; HP Connection Optimizer; HP Privacy Settings; HP PC Hardware Diagnostics Windows; HP Desktop Support Utilities; HP Easy Clean; Touchpoint Customizer for Commercial; HP Easy Clean Keyboard Driver; HSA Fusion for Commercial; HSA Telemetry for Commercial; HPX for CMIT

Operating humidity range

10 to 90% RH

Operating temperature range

50 to 95°F

Dimensions (W X D X H)

10.6 x 3.7 x 12.1 in

Weight

9.25 lb

Package weight

5.97 lb
