TPLINK TL-EAP610 AX1800 WIRELESS DUAL BAND CEILING MOUNT ACCESS POINT [SBN:NO NILAI:NO MELAKA:NO HPS:NO]

Name: TPLINK TL-EAP610 AX1800 WIRELESS DUAL BAND CEILING MOUNT ACCESS POINT [SBN:NO NILAI:NO MELAKA:NO HPS:NO] | Thye Hin Computer
SKU: N7169
Price: 619.00 MYR
Availability: OutOfStock

RM619.00

EAP610 is an AX1800 Ceiling Mount WiFi 6 Access Point, and is ideal for networking upgrade to WiFi 6, such as offices, campuses, retails, and hotels. With WiFi 6 technology, it provides faster speeds, less lag, and higher capacity. The advanced functions including Omada Mesh, Seamless Roaming, MU-MIMO, Captive Portal further boost network security, efficiency, and coverage.

Additionally, this product is integrated into Omada Software Defined Networking (SDN) system, and can be centrally managed with cloud access via Omada Hardware Controller or Software Controller. The ability to control, adjust, and visualize the entire network from any connected PC makes centralized business Wi-Fi management efficient than ever before.

Out of stock

SKU: N7169 Categories: Brand, Networking, Tplink, Whole Home Wifi System

TPLINK TL-EAP610 AX1800 WIRELESS DUAL BAND CEILING MOUNT ACCESS POINT

HARDWARE FEATURES
Interface 1× Gigabit Ethernet (RJ-45) Port (supports IEEE802.3at PoE)
Button Reset

Power Supply

• 802.3at PoE
• 12 V / 1 A DC

Power Consumption

• EU: 12.8 W (For PoE); 10.8 W (for DC)
• US: 13.9W (For PoE); 11.8 W (for DC)

Dimensions ( W x D x H ) 9.6 × 9.6 × 2.5 in (243 × 243 × 64 mm)

Antenna Type Internal Omni
• 2.4 GHz: 2× 4 dBi
• 5 GHz: 2× 5 dBi

Mounting Ceiling /Wall Mounting (Kits included)

WIRELESS FEATURES
Wireless Standards IEEE 802.11ax/ac/n/g/b/a
Frequency 2.4 GHz and 5 GHz

Signal Rate

5 GHz: Up to 1201 Mbps
2.4 GHz: Up to 574 Mbps

Wireless Functions

• 1024-QAM
• 4× Longer OFDM Symbol
• OFDMA
• Multiple SSIDs (Up to 16 SSIDs, 8 for each band)
• Enable/Disable Wireless Radio
• Automatic Channel Assignment
• Transmit Power Control (Adjust Transmit Power on dBm)
• QoS(WMM)
• MU-MIMO
• Seamless Roaming
• Omada Mesh
• Band Steering
• Load Balance
• Airtime Fairness
• Beamforming
• Rate Limit
• Reboot Schedule
• Wireless Schedule
• Wireless Statistics based on SSID/AP/Client

Wireless Security

• Captive Portal Authentication
• Access Control
• Wireless Mac Address Filtering
• Wireless Isolation Between Clients
• SSID to VLAN Mapping
• Rogue AP Detection
• 802.1X Support
• WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise

Transmission Power

• CE:
<20 dBm(2.4 GHz, EIRP)
<23 dBm(5 GHz, EIRP)

• FCC:
<25 dBm (2.4 GHz)
<25 dBm (5 GHz)

MANAGEMENT
Omada App Yes

Centralized Management

• Omada Hardware Controller (OC300)
• Omada Hardware Controller (OC200)
• Omada Software Controller

Cloud Access   Yes (Through OC300, OC200, or Omada Software Controller)
Email Alerts   Yes
LED ON/OFF Control   Yes
Management MAC Access Control   Yes
SNMP   v1, v2c, v3
System Logging Local/Remote Syslog   Local/Remote Syslog
SSH   Yes
Web-based Management   HTTP/HTTPS
L3 Management   Yes
Multi-site Management   Yes
Management VLAN   Yes

OTHERS
Certification CE, FCC, RoHS

Package Contents

• EAP610
• Power Adapter
• Ceiling/Wall Mounting Kits
• Installation Guide

System Requirements Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Linux

Environment

• Operating Temperature: 0–40 ℃ (32–104 ℉)
• Storage Temperature: -40–70 ℃ (-40–158 ℉)
• Operating Humidity: 10–90% RH non-condensing
• Storage Humidity: 5–90% RH non-condensing
