INTEL CORE I7-13700K PROCESSOR 3.4GHZ PROCESSOR [SBN:NO NILAI:NO MELAKA:NO HPS:NO]

INTEL CORE I7-13700K PROCESSOR 3.4GHZ PROCESSOR

Essentials
Product Collection        13th Generation Intel® Core™ i7 Processors
Code Name            Products formerly Raptor Lake
Vertical Segment        Desktop
Processor Number         i7-13700K
Lithography             Intel 7
Use Conditions             PC/Client/Tablet, Workstation

CPU Specifications
Total Cores         16
# of Performance-cores        8
# of Efficient-cores        8
Total Threads         24
Max Turbo Frequency        5.40 GHz
Intel® Turbo Boost Max Technology 3.0 Frequency     5.40 GHz
Performance-core Max Turbo Frequency         5.30 GHz
Efficient-core Max Turbo Frequency            4.20 GHz
Performance-core Base Frequency            3.40 GHz
Efficient-core Base Frequency                2.50 GHz
Cache             30 MB Intel® Smart Cache
Total L2 Cache        24 MB
Processor Base Power         125 W
Maximum Turbo Power        253 W

Supplemental Information
Embedded Options Available         No

Memory Specifications
Max Memory Size (dependent on memory type)         128 GB
Memory Types             Up to DDR5 5600 MT/s
                Up to DDR4 3200 MT/s
Max # of Memory Channels     2
Max Memory Bandwidth     89.6 GB/s
ECC Memory Supported         Yes

Processor Graphics
Processor Graphics         Intel® UHD Graphics 770
Graphics Base Frequency     300 MHz
Graphics Max Dynamic Frequency     1.60 GHz
Graphics Output             eDP 1.4b, DP 1.4a, HDMI 2.1
Execution Units             32
Max Resolution (HDMI)        4096 x 2160 @ 60Hz
Max Resolution (DP)        7680 x 4320 @ 60Hz
Max Resolution (eDP – Integrated Flat Panel)        5120 x 3200 @ 120Hz
DirectX* Support         12
OpenGL* Support         4.5
OpenCL* Support         3.0
Multi-Format Codec Engines     2
Intel® Quick Sync Video         Yes
Intel® Clear Video HD Technology         Yes
# of Displays Supported        4
Device ID            0xA780

Expansion Options
Direct Media Interface (DMI) Revision        4.0
Max # of DMI Lanes        8
Scalability            1S Only
PCI Express Revision         5.0 and 4.0
PCI Express Configurations    Up to 1×16+4, 2×8+4
Max # of PCI Express Lanes    20

Package Specifications
Sockets Supported         FCLGA1700
Max CPU Configuration        1
TJUNCTION             100°C

Advanced Technologies
Intel® Gaussian & Neural Accelerator         3.0
Intel® Thread Director            Yes
Intel® Deep Learning Boost (Intel® DL Boost)     Yes
Intel® Speed Shift Technology         Yes
Intel® Turbo Boost Max Technology 3.0        Yes
Intel® Turbo Boost Technology            2.0
Intel® Hyper-Threading Technology        Yes
Intel® 64        Yes
Instruction Set         64-bit
Instruction Set Extensions         Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2
Idle States         Yes
Enhanced Intel SpeedStep® Technology         Yes
Thermal Monitoring Technologies         Yes
Intel® Volume Management Device (VMD)     Yes

Security & Reliability
Intel® Standard Manageability (ISM)         Yes
Intel® Control-Flow Enforcement Technology     Yes
Intel® AES New Instructions             Yes
Secure Key         Yes
Intel® OS Guard        Yes
Intel® Trusted Execution Technology         Yes
Execute Disable Bit        Yes
Intel® Boot Guard         Yes
Mode-based Execute Control (MBEC)         Yes
Intel® Virtualization Technology (VT-x)        Yes
Intel® Virtualization Technology for Directed I/O (VT-d)        Yes
Intel® VT-x with Extended Page Tables (EPT)             Yes
