Projection Technology:
Projection Technology:RGB liquid crystal shutter projection system (3LCD)
Specifications of Main Parts:
LCD:Size: 0.61” wide panel (C2 Fine, 10 bit)
Native Resolution: 1080pProjection Lens:Type: Optical Zoom (Manual) / Focus (Manual)
F-Number: 1.49 – 1.77
Focal Length: 18.2 – 29.2 mm
Zoom Ratio: 1 – 1.62Lamp:Type: 250W UHE
Life (High / Medium / Eco)*1: 3,500 / 4,000 / 5,000 hoursScreen Size (projected distance):Standard size: 100″ screen [2.95 to 4.77 m]
Wide: 40″ to 500″ [1.16 to 14.87 m]
Tele: 40″ to 500″ [1.89 to 24.01 m]
Brightness1:
White Light Output (Normal/Eco):3,000 lm / 2,000 lmColour Light Output:3,000 lm
Connectivity:
USB Interface:USB Type A: 2 (Port 1: Wireless LAN, Firmware Update, Copy OSD Settings / Port 2: For Streaming Media Player with 2,000 mA Power Supply)
USB Type Mini-B: 1Network:Wired LAN: N/A
Wireless: Optional (ELPAP10)Analog Input:D-Sub 15Pin: N/A
5BNC: N/ADigital Input:DVI-D: N/A
HDMI Type A: 2 (HDCP 2.2)
SDI: N/A
HDBaseT: N/AOutput Terminal:D-Sub 15Pin: N/AAudio Input:Stereo Mini Jack: N/AAudio Output:Stereo Mini Jack: 1Control I/O:RS-232C: N/A
Remote Control Input: N/A
Contrast Ratio:
Contrast Ratio:40,000:1
Geometric Correction:
Vertical/Horizontal Keystone:± 30 degrees
Adjustment Functions:
Picture In Picture:N/AAspect Mode:YesFrame Interpolation:Off / Low / Normal / High (2D and 3D Mode)
Image Enhancement:
Image Preset Mode:YesMpeg Noise Reduction:YesSuper Resolution:Yes
4K Enhancement:
Yes (On/Off)Detail Enhancement:Yes
Start-Up Period:
Start-Up Period:Up to 19 seconds
Warm-up period: 30 seconds
Operating Temperature:
Operating Temperature:5 – 35 °C <41 – 95 °F> (0m / 0ft – 2,286m / 7,500ft)
5 – 30 °C <41 – 86 °F> (Over 2,286 m / 7,500 ft)
(20% – 80% humidity, No condensation)
Operating Altitude:
Operating Altitude:0 – 3,048 m <0 -10,000 ft>
Dimension Excluding Feet (W x H x D):
Fan Noise (Normal/Eco):35dB / 24dBDimension Excluding Feet (W x H x D):410 x 157 x 310 mm
Weight:
Weight:Approx. 6.6kg
Direct Power On/Off:
Direct Power On/Off:Yes / NA
3D Features:
3D Display:Yes3D Format:Side by Side / Top and Bottom3D Depth:-10 to +102D – 3D Conversion:N/A
Optional Wireless & Built In Lan Specifications:
Supported Speed for each Mode:IEEE 802.11g (2.4GHz): 11 Mbps*3
IEEE 802.11b (2.4GHz): 54 Mbps*3
IEEE 802.11n (2.4GHz): 130 Mbps*3Wireless LAN Security:Quick Mode: WPA2-PSK
Advanced Mode: WPA/WPA2-PSKSupported Connection Mode:Infrastructure, Access Point
Cool Down Period:
Cool Down Period:Up to 7 seconds
Fan Noise:
Fan Noise (Normal / Eco):35 dB / 24dB
Projectors Facets:
4K PRO-UHD, Projectors Facets:YesFeatures, Projectors Facets:Quick CornerLaser / Lamp, Projectors Facets:LampScreen Size, Projectors Facets:40 – 500Projector Primary Usage, Projectors Facets:Living Room
Home Entertainment
Home TheaterResolution, Projectors Facets:4K PRO-UHDContrast Ratio, Projectors Facets:40,000:1Brightness Range Lumens, Projectors Facets:2000
