EPSON EB-E12 PROJECTOR XGA 3LCD 3600LM 1024*768 6000 HOURS 1 YEAR
-
Projection technology:
-
RGB liquid crystal shutter projection system (3LCD)
-
-
Brightness:
-
White light output (Normal/Eco): 3,600 lm / 2,200 lm
-
Colour light output: 3,600 lm
-
Light output (Center): 3,700 lm
-
-
Connectivity:
-
Network: N/A
-
Analog input:
-
D-Sub 15-pin: N/A
-
RCA: N/A
-
-
Digital input:
-
HDMI Type A: 2 (HDCP 1.4)
-
-
Analog output:
-
D-Sub 15-pin: N/A
-
-
Audio input:
-
Stereo mini: N/A
-
-
Audio output:
-
Stereo mini: N/A
-
-
Control I/O:
-
RS-232C: N/A
-
-
USB input:
-
USB Type B: 1 (for firmware update, copy OSD settings)
-
-
-
Contrast ratio:
-
15,000:1
-
-
Screen size (projected distance):
-
Zoom wide: 30" – 350" [0.87 – 10.34 m]
-
Zoom tele: 15" – 175" [0.87 – 10.34 m]
-
-
Geometric correction:
-
Vertical/horizontal keystone: ±30° / ±30°
-
-
Operating temperature:
-
Low altitude (0 – 2,286 m / 7,500 ft): 5 – 40 °C (41 – 104 °F)
-
High altitude (over 2,286 m / 7,500 ft): 5 – 35 °C (41 – 95 °F)
-
20% – 80% humidity, no condensation
-
-
Operating altitude:
-
Over 1,500 m / 4,921 ft with High Altitude Mode: 0 – 3,048 m (0 – 10,000 ft)
-
-
Start-up period:
-
Less than 7 seconds (Epson logo); warm-up period: 30 seconds
-
-
Cool down period:
-
Instant off
-
-
Internal speaker(s):
-
Sound output: Monaural 2W x 1
-
-
Weight:
-
Approx. 2.4 kg
-
-
Air filter:
-
Maintenance cycle: 6,000 hours (Normal) / 12,000 hours (Eco)
-
-
Fan noise:
-
Normal / Eco: 37 dB / 28 dB
-
-
Power consumption (220–240 V):
-
Lamp (Normal / Extended): 332 W / 231 W
-
Standby (Normal / Eco): N/A / 0.3 W
-
-
Direct power on/off:
-
Yes
-
-
Dimension excluding feet (W x D x H):
-
302 x 234 x 77 mm
-
-
Power supply:
-
Voltage: 100 – 240 V AC ±10%, 50/60 Hz
-
-
Specifications of main parts:
-
LCD:
-
Size: 0.55" (C2 Fine)
-
Driving method: Poly-silicon TFT active matrix
-
Pixel number: 786,432 dots (1024 x 768) x 3
-
Native resolution: XGA
-
Aspect ratio: 4:3
-
Pixel arrangement: Cross stripe
-
-
-
Light source:
-
Lamp type: 210 W UHE
-
Life (Normal / Eco): 6,000 hours / 12,000 hours
-
-
Projection lens:
-
Type: No optical zoom / Focus (manual)
-
F-number: 1.44
-
Focal length: 16.7 mm
-
Zoom ratio: 1.0 – 2.0 (digital zoom)
-
Throw ratio: 1.44 – 2.88
-
